Miele Design System

Overview

Miele's marketing page builds its identity on a binary axiom that few appliance brands hold. Black-white precision. The navigation band is pure black (#000000), the page body is pure white, and the two tones account for over 260 of the 300+ total captured color occurrences. Unlike Bosch (which uses a blue accent across every interactive element) or Samsung (which deploys gradient fills and colored chip UI), Miele allocates its single chromatic token — amber-gold (#f59b00) — to exactly 9 page occurrences, all as promotional button fills or product-badge fills. The amber appears only when Miele wants to mark something as a direct commercial action; it does not appear in navigation, does not appear in card grids, and does not appear as a text color anywhere on the page.

Typography runs a proprietary Helvetica Neue stack — four weights accessed via separate font-face names (45Ligh, 55Roma, 65Medi, 75Bold) — with all declared fontWeight values at 400 because the weight differentiation is encoded inside the font files rather than the CSS weight property. The button system is the most technically declared surface in the extraction: 17 CSS custom properties govern height (3rem), horizontal padding (2.9375rem), and four interaction states (default, hover, focus, disabled).

Key Characteristics:

• Pure binary chrome: #000000 ink (217 occurrences) and #ffffff canvas (43 occurrences) — no grey surface in the hero or editorial sections.
• Amber-gold #f59b00 at maximum scarcity — 9 total occurrences, exclusively as promotional CTA fill or product badge, classified as layer:brand.
• Four-weight Helvetica Neue family (45Ligh / 55Roma / 65Medi / 75Bold) accessed via separate web-font face names, all at CSS fontWeight:400.
• 17-variable CSS custom-property button system with explicit hover, focus, and disabled states.
• Zero border-radius throughout — every button, card, input, and select element is sharp-cornered.
• Dense micro-spacing: 5px, 9px, 10px are the primary internal spacing values; card padding at 16px; section padding sparse.
• Crimson link-hover (#8c0014) declared in CSS variables but never rendered in the static capture — exists entirely in the interactive state layer.

Colors

Ink

• Ink ({colors.ink} — #000000): frequency 217. Used as text (114), border (101), background (2). The dominant page tone — fills the navigation band, every hairline border, and the primary button background. Pure black, not near-black.
• Ink Near ({colors.ink-near} — #191919): frequency 24. Used as text (10), border (11), background (3). Clustered from two near-black hex values in the extraction. Wired as --obj-button-background--default and --obj-link-color. The near-black that carries the button-primary fill and the link text color.
• Ink Mid ({colors.ink-mid} — #808080): frequency 4. Used as text (2), border (2). Clustered from two near-grey hex values in the extraction. Mid-grey for secondary metadata text.
• Ink Light ({colors.ink-light} — #c4c4c4): frequency 12. Used as text (6), border (6). The light-grey hairline tone for card borders and dividers.

Canvas

• Canvas ({colors.canvas} — #ffffff): frequency 43. Used as text (18), border (18), background (7). Clustered from three near-white hex values in the extraction. The page body floor and button text color. Wired as --obj-button-color.
• Canvas Disabled ({colors.canvas-disabled} — #e2e2e2): zero rendered occurrences — declared only as --obj-button-background--disabled. Reserved for disabled button states.

Brand

• Accent Amber ({colors.accent-amber} — #f59b00): frequency 9. Used as background (5), text (2), border (2). The sole brand-layer color in the system. Appears on the "LEARN MORE" promotional CTA in the hero and on product-tier badge fills. Absent from navigation, card chrome, and body text.

Interactive States

• Button Hover ({colors.button-hover} — #6b6b6b): zero rendered occurrences — declared as --obj-button-background--hover and --obj-button-background--focus. The mid-grey that replaces the near-black button fill on hover.
• Link Hover ({colors.link-hover} — #8c0014): zero rendered occurrences — declared as --obj-link-hover-color, --obj-link-hover-icon-color, --obj-link-icon-color. A deep crimson-red that fires on text-link hover. Not part of the visible chrome; part of the interactive state layer.

Typography

Font Family

The system runs Helvetica Neue in a proprietary four-weight web-font stack where each weight is loaded as a separately-named face: HelveticaNeueW01-45Ligh (Light), HelveticaNeueW01-55Roma (Roman/Regular), HelveticaNeueW01-65Medi (Medium), HelveticaNeueW01-75Bold (Bold). All CSS declarations use fontWeight: 400 — the actual optical weight comes from the loaded font file. This pattern means that swapping to a standard Helvetica Neue fallback will flatten all text to a single weight.

Hierarchy

Principles

The 12px body text at 16px line-height (1.33 ratio) is the tightest body rhythm in this directory for a marketing surface — appropriate for a brand whose page functions more like a product catalog than an editorial magazine. The nav band runs Bold at 14px with a collapsed 10px line-height, giving top-bar links the density of a German engineering spec sheet.

Note on Font Substitutes

The HelveticaNeueW01 family requires a Linotype license. Inter covers all four weight roles cleanly; use font-weight 300 / 400 / 500 / 700 to approximate the four face names. Work Sans is a slightly narrower alternative at display sizes.

Layout

Spacing System

• Base unit: 5px micro-unit, with 10px as the primary module.
• Tokens: {spacing.xxs} 2px · {spacing.xs} 5px · {spacing.sm} 9px · {spacing.base} 10px · {spacing.md} 16px · {spacing.lg} 28px · {spacing.xl} 48px · {spacing.2xl} 160px.
• Button padding: --obj-button-padding-horizontal: 2.9375rem (~47px) — an unusually precise value set by CSS custom property rather than a round spacing token.
• Card internal padding: 16px on editorial content cards.
• Section padding: sparse — the page delivers content in dense blocks with minimal inter-section breathing room compared to the luxury peers in this directory.

Grid & Container

• Nav band: full-width pure black, ~48px height, with centered wordmark and right-aligned customer-type toggle (Trade / Domestic customers).
• Hero: full-bleed product photography with promotional CTA overlay (amber button bottom-right).
• Below-fold editorial grid: 3-column card layout with product photography + minimal text + "Read more" links.
• Footer: full-width pure black footer with white text — mirrors the nav band geometry.

Rhythm

The page alternates between dense (full-bleed photography, tight card grid) and sparse (single editorial paragraph, map element) bands. Unlike Van Cleef & Arpels' generous 60–90px section margins, Miele packs more content per vertical unit — the aesthetic is catalog efficiency rather than editorial breathing room.

Elevation

The captured surface has no shadow tier. Zero shadow occurrences in the extraction. Cards are separated from the background by hairline borders ({colors.ink-light} — #c4c4c4) and by flat white-on-white surface contrast rather than any elevation. The nav band sits flush with a hard background-color break rather than a drop shadow. The absence of shadow reinforces the binary flatness of the system.

Shapes

The radius vocabulary is zero everywhere. No border-radius values appear in the extraction for any button, card, input, or container. The single radius token {rounded.none} covers the entire system; the full-pill token ({rounded.full}) is included as an available value but not rendered in the captured marketing surface. Miele's hard corners are the typographic equivalent of a product spec sheet — no softening, no rounding, no concession.

Components

button-primary — Near-black {colors.ink-near} fill, white text at {typography.button-md} (14px / 800), zero radius, 47px horizontal padding, 48px height. Driven by the --obj-button-* CSS custom-property system. The most geometrically precise component in the system.

button-primary-hover — Mid-grey {colors.button-hover} (#6b6b6b) fill replaces the near-black on hover. Same dimensions. Wired to --obj-button-background--hover.

button-primary-disabled — Light grey {colors.canvas-disabled} (#e2e2e2) fill, mid-grey text. Wired to --obj-button-background--disabled.

button-secondary — Transparent fill, black text, 1px black border. Same dimensions as primary. Used for the "Confirm selection" secondary action on the cookie consent panel.

button-amber — Amber {colors.accent-amber} fill, white text in uppercase {typography.label-md} (11px Medium), 6×8px padding, 32px height, zero radius. The promotional CTA button — "LEARN MORE" in the hero bottom-right. The only chromatic button in the system.

top-nav — Pure black {colors.ink} surface, white text, 48px height. Miele logo in white centered; a customer-type toggle (Trade / Domestic) sits right-aligned. Bottom hairline in white at very low opacity.

nav-link — Transparent background, white text in {typography.nav-link} (14px Bold). 0×7px padding (right-gapped).

hero-heading — Black text on transparent background at {typography.display-md} (24px Roma). Note: the extraction's heroHeading captured a cookie-consent h3 rather than the true marketing hero headline, which is behind the cookie overlay.

body-paragraph — Black text, {typography.body-md} (12px / 16px). The tight 1.33 line-height is the defining body-copy characteristic.

label-uppercase — Medium weight {typography.label-md} (11px / 1px tracking), uppercase, for category chip labels and section annotators.

card-hairline — White canvas, black text, 1px light-grey border ({colors.ink-light}), zero radius, 16px padding. The editorial content card.

card-image — White canvas, photography-first — product image fills the card face with text below. Zero padding on image, text portion at 16px.

footer — Pure black {colors.ink} fill, white text, 28px vertical padding. Mirrors the nav band. Social icons, legal links, and site-map links in white.

link-text — Transparent background, near-black {colors.ink-near} text in {typography.link-sm} (14px / 21px). "Read more" links with crimson hover state declared in CSS variables.

form-label — Transparent, black text at {typography.form-label} (16px / 20px). Form field labels on the cookie consent panel.

Do's and Don'ts

Do limit the amber {colors.accent-amber} (#f59b00) to direct commercial actions only — promotional CTAs, product-tier badges, and selection submit buttons. Using it for navigation highlights, card borders, or icon fills would destroy the scarcity that makes it read as a luxury signal rather than a promotional decoration.

Do use the --obj-button-* CSS custom-property system for all button variants. The 17 declared variables cover height, padding, color, and all four interaction states — implementing buttons outside this system will produce inconsistent geometry.

Do keep body text at 12px in {typography.body-md}. The tight 16px line-height is a deliberate catalog-density choice. Bumping to 16px text at 24px line-height shifts the register from product specification toward editorial commentary.

Do hold the top-nav and footer at pure black {colors.ink} (#000000). The binary black header / white body / black footer sandwich is the structural signature of the page; using a near-black or dark-grey for either band loses the graphic precision.

Don't add border-radius to any button or card. The entire system is zero-radius — even 4px rounded corners would introduce softness that conflicts with the German-engineering specification aesthetic. If the button or card needs to feel approachable, change the text, not the corners.

Don't use {colors.ink-light} (#c4c4c4) for text. It is a hairline-border-only token (6 text occurrences, all on border elements, zero on pure prose). For secondary text, use {colors.ink-mid} (#808080).

Don't apply {colors.link-hover} (#8c0014) to any static element. The crimson is an interactive-state-only token that fires on hover — using it as a static text color or icon fill would confuse it with an error or warning semantic.

Don't use the amber {colors.accent-amber} for text at body sizes. Its 9 occurrences split 5 background / 2 text / 2 border, and the 2 text occurrences are on button labels against the amber fill. At 12–14px on a white canvas, amber text falls below accessible contrast ratios.

Known Gaps

• Hero marketing content: the extractor captured the cookie-consent overlay as the primary content surface; the actual hero product photography, hero headline, and promotional carousel are blocked behind it and not represented in the component extraction.
• Product detail pages: this DESIGN.md covers the home/landing surface. Miele's product pages (washing machines, refrigerators, vacuum cleaners) likely expose additional comparison table, specification grid, and configurator tokens.
• Dark canvas surfaces: the nav and footer are dark, but no mid-dark surface (charcoal, dark grey) appears in the system. If dark-mode or dark-canvas editorial sections exist in product-specific marketing, they are not represented here.
• Animation and transitions: Miele's product carousels and scroll reveals use CSS transitions; timing and easing are not captured by the static extractor.
• International variants: the extracted URL is the global English site; regional variants (DE, US, UK) may use different section ordering, promotional colors, or typography scales.
